Desert-Cut Bohrer
Desert Cut Logo_Trademark

Desert-cut drills

for dry machining
The Desert-Cut series was developed to significantly improve the processing of aluminum profiles. The elimination of any cooling lubricants in particular offers numerous advantages. A detailed description of all the advantages that result from the use of the Desert-Cut tools can be found under the following link:
Desert-Cut Stufenbohrer
Desert Cut Logo_Trademark

Solid carbide drills

for dry machining
Zeichnung Desert-Cut Stufenbohrer

D1 = pre-drilling diameter

D2 = shank diameter

D3 = drilling diameter

L1 = total length

L2 = pre-drilling length

L3 = drilling length

Cutting speed vc (m/min) = 300-400

Feed per tooth fz (mm) = 0.07-0.3

Artikel Nr. D1/D3 D2 L1 L2/L3
209 020 1/2 6 50 2/10
209 030 2/3 6 50 2/10
209 040 3/4 6 60 2/12
209 050 4/5 6 70 2/15
209 060 5/6 6 70 2/17
209 070 6/7 8 90 2/18
209 080 7/8 8 100 2/18
Burr-free processing

Please contact us for more information, personal advice, customized tools or an individual offer.

ein Desert-Cut Kernlochbohrer
Desert Cut Logo_Trademark

Solid carbide core drills

for dry machining
ein Kernlochbohrer

D1 = drilling diameter

D2 = shank diameter

L1 = total length

L2 = drilling length

Cutting speed vc (m/min) = 300-400

Feed per tooth fz (mm) = 0.07-0.3

Artikel Nr. D1 D2 L1 L2 Gewinde
219 025 2,5 6 50 10 M3
219 033 3,3 6 50 10 M4
219 042 4,2 6 60 12 M5
219 050 5,0 6 70 15 M6
219 068 6,8 8 70 17 M8
219 085 8,5 10 90 18 M10
219 102 10,2 12 100 18 M12

Please contact us for more information, personal advice, customized tools or an individual offer.

More products of the Desert-Cut series

Milling cutters

Circular saw blades
